ACCE

Every Ampex data recorder ships with the Ampex Common Compute Environment (ACCE) pre-installed, providing a unified, mission-ready interface for data acquisition, management, and control right out of the box. The beauty of this software-defined approach lies in its shift from traditional, often rigid, hardware-defined paradigms to a more adaptable, software-centric model.

All Products

Product	Features	Size / Weight	Speed	Storage	Interfaces	Security
BASE Our most economical option. Mission required capabilities.
CAR PRODUCT PAGE DATASHEET	Perfect For Attritable Systems, Combining Small Form Factor With High Performance 2 TB Fixed Storage Or Up To 512 GB Of Removable CFast Storage Modular Linux Based Open Architecture Standard: 2x 1 GbE GNSS/GPS Receiver (W/ Disable Feature)	1.8” H x 4.8” W x 6.8” D 2 lbs	200 MB/sec	2 TB	2x GbEAudioGPS	Self Encrypting Drive
TuffCORDv2 PRODUCT PAGE DATASHEET	Removable Storage Capacity Up To 20 TB Standard Dual 1 GbE Interfaces Greater Than 250 MB/sec Sustained Network Throughput Expandability And Flexibility: Customizable I/O Options Built Rugged, MIL-STD-810 With MIL-STD Connectors	3.6” H x 4.8” W  x 6.3” D 5.5 lbs	250 MB/sec	20 TB	2x GbE	AES 256/FIPS 197FIPS 140, CSfC
PLUS Most popular solution. The “sweet spot” between cost & capabilities.
TuffCORD-X PRODUCT PAGE DATASHEET	10GbE and 1GbE interfaces 750 MB/s Sustained Network Throughput NVMe Architecture Removable Storage Capacity Up To 16TB Expandability And Flexibility: Customizable I/O Options Built Rugged, MIL-STD-810 With MIL-STD Connectors	3.6” H x 4.8” W  x 6.3” D 5.5 lbs	750 MB/sec	16 TB	10 GbE 1 GbE	AES 256/FIPS 197FIPS 140CSfC
TuffLITE PRODUCT PAGE DATASHEET	High-Speed I/O: Equipped With 10GbE Interface Over 8TB (Detachable) Capable Of Ingest, Pass Through, And Reproduction Video Specifically Crafted To Meet The Stringent Size, Weight, And Power (SWaP) Requirements Of Compact Platforms	1.28” H x 6.12” W x 6.69” D 2.5 lbs	1,100 MB/sec	8 TB	10 GbE1 GbE2.5 GbEVideoRS 422	AES 256/FIPS 197FIPS 140CSfC
TuffServ^® 282 PRODUCT PAGE DATASHEET	More Than 200 MB/sec Sustained Read Or Write Throughput Six Second Full Load Power Holdup Standard Dual Gigabit Ethernet Interfaces Two Removable Memory Modules Built Rugged, MIL-STD-810 With MIL-STD Connectors	9.0” H x 4.8” W  x 11.0” D 14.6 lbs	200 MB/sec	16 TB+	4x GbE10/100 Fast Ethernet	AES 256/FIPS 197FIPS 140CSfC
TuffServ^® 480v2 PRODUCT PAGE DATASHEET	Removable Storage Capacity 16 TB Or Higher Various Recording Formats Including CH 10 And PCAP Optional Optical 10 GbE Interface Expandability And Flexibility: Customizable I/O Options Built Rugged, MIL-STD-810 With MIL-STD Connectors	5.25” H x 7.25” W x 10.0” D 17.5 lbs 17.5 lbs	375 MB/sec	16 TB+	2x GbE, 2x 10 GbE optional	AES 256/FIPS 197FIPS 140CSfC
MAX The fastest thing flying. Fully capable. Completely rugged.
TuffServ^® 540 PRODUCT PAGE DATASHEET	Removable Storage Capacity Up To 16 TB Small And Lightweight 105 cu. In, And Less Than 10 lbs Optional Optical 10 GbE Interface Expandability And Flexibility: Customizable I/O Options Special Radiant Tolerant Version Suitable For High Altitude And Space	2.9” H x 4.25” W  x 8.5” D 10 lbs	800 MB/sec	16 TB	2x GbE10/100 Fast Ethernet	AES 256/FIPS 197FIPS 140CSfC
TuffServ^® 640v2 PRODUCT PAGE DATASHEET	Removable Storage Capacity Up To 300 TB Quad 10 GbE Optical Interfaces Suitable For Edge-Operating AI/ML Applications; Tested And Validated Expandability And Flexibility: Customizable I/O Options Can Record IRIG 106 Chapter 10 data format	7.63” H x 4.88” W x 12.63″ D 30 lbs	3 GB/sec	300 TB	4x 10GbE, 1 GbE	AES 256/FIPS 197FIPS 140CSfC
FLIGHT TEST Where every pulse, signal, and sensor detail matters.
miniRv2 PRODUCT PAGE DATASHEET	IRIG 106 CH 10 File Format Outputs CH 10/11 Data As A CH 7 Serial PCM Stream Totally Flexible & Modular I/O Sustained Data Rates To 1,000 Mb/sec Up To 2 TB Of Removable Storage	4.125” H x 3.5” W x 6.82” D 4.6 lbs	1,000 Mb/sec	2 TB	1 GbE10/100 Fast EthernetRS 232/422″Slice-based” expansion Fully expandable “Slice-based” system supports a multitude of interfaces	AES 256/FIPS 197FIPS 140TurnstileCSfC
RACK MOUNT Where industry-leading design meets peak operational performance.
TRS-X PRODUCT PAGE DATASHEET	Sustained Data Rate Of 100 Gb/sec Scalable: Virtually Unlimited Storage/Capacity QSFP Optical Interfaces Multiple Expansion Sites For Additional I/O Industry Standard Architecture And Commodity SSDS	19” W x 3.5” H x 20” D (Chassis), 19” W x 1.75” H x 22” D (Removable Storage Tray) 40 lbs	Config A: up to 100Gb, Config B: 10-40Gb	187 TB+, Varies by Configuration	2x 100 GbE2x GbE (1 Shared with IPMI)	AES 256/FIPS 197FIPS 140CSfC
DOWNLOAD STATION Efficient data download, encryption key handling, and data encryption/decryption.
SmartDock® PRODUCT PAGE DATASHEET	miniRv2 or TuffCORD RMM rapid data download Encryption key handling and data management Fast 10 Gb/s network support LCD panel for status Easy-to-use Web GUI interface for status, download, and encryption key management	4.5” H x 8.6” W 9.2” D 4.75lbs	10 Gb/s		10 GbE download interface	AES 256/FIPS 197, FIPS-140, CSfC

BASE Our most economical option. Mission required capabilities.

CAR

PRODUCT

DATASHEET

Features

Perfect For Attritable Systems, Combining Small Form Factor With High Performance
2 TB Fixed Storage Or Up To 512 GB Of Removable CFast Storage
Modular Linux Based Open Architecture
Standard: 2x 1 GbE
GNSS/GPS Receiver (W/ Disable Feature)

Size/Weight

1.8” H x 4.8” W x 6.8” D

2 lbs

Speed

200 MB/sec

Storage

2 TB

Interfaces

2x GbEAudioGPS

Security

Self Encrypting Drive

TuffCORDv2

PRODUCT

DATASHEET

Features

Removable Storage Capacity Up To 20 TB
Standard Dual 1 GbE Interfaces
Greater Than 250 MB/sec Sustained Network Throughput
Expandability And Flexibility: Customizable I/O Options
Built Rugged, MIL-STD-810 With MIL-STD Connectors

Size/Weight

3.6” H x 4.8” W  x 6.3” D

5.5 lbs

Speed

250 MB/sec

Storage

20 TB

Interfaces

2x GbE

Security

AES 256/FIPS 197FIPS 140, CSfC

PLUS Most popular solution. The “sweet spot” between cost & capabilities.

TuffCORD-X

PRODUCT

DATASHEET

Features

10GbE and 1GbE interfaces
750 MB/s Sustained Network Throughput
NVMe Architecture
Removable Storage Capacity Up To 16TB
Expandability And Flexibility: Customizable I/O Options
Built Rugged, MIL-STD-810 With MIL-STD Connectors

Size/Weight

3.6” H x 4.8” W  x 6.3” D

5.5 lbs

Speed

750 MB/sec

Storage

16 TB

Interfaces

10 GbE 1 GbE

Security

AES 256/FIPS 197FIPS 140CSfC

TuffLITE

PRODUCT

DATASHEET

Features

High-Speed I/O: Equipped With 10GbE Interface
Over 8TB (Detachable)
Capable Of Ingest, Pass Through, And Reproduction Video
Specifically Crafted To Meet The Stringent Size, Weight, And Power (SWaP) Requirements Of Compact Platforms

Size/Weight

1.28” H x 6.12” W x 6.69” D

2.5 lbs

Speed

1,100 MB/sec

Storage

8 TB

Interfaces

10 GbE1 GbE2.5 GbEVideoRS 422

Security

AES 256/FIPS 197FIPS 140CSfC

TuffServ^® 282

PRODUCT

DATASHEET

Features

More Than 200 MB/sec Sustained Read Or Write Throughput
Six Second Full Load Power Holdup
Standard Dual Gigabit Ethernet Interfaces
Two Removable Memory Modules
Built Rugged, MIL-STD-810 With MIL-STD Connectors

Size/Weight

9.0” H x 4.8” W  x 11.0” D

14.6 lbs

Speed

200 MB/sec

Storage

16 TB+

Interfaces

4x GbE10/100 Fast Ethernet

Security

AES 256/FIPS 197FIPS 140CSfC

TuffServ^® 480v2

PRODUCT

DATASHEET

Features

Removable Storage Capacity 16 TB Or Higher
Various Recording Formats Including CH 10 And PCAP
Optional Optical 10 GbE Interface
Expandability And Flexibility: Customizable I/O Options
Built Rugged, MIL-STD-810 With MIL-STD Connectors

Size/Weight

5.25” H x 7.25” W x 10.0” D 17.5 lbs

17.5 lbs

Speed

375 MB/sec

Storage

16 TB+

Interfaces

2x GbE, 2x 10 GbE optional

Security

AES 256/FIPS 197FIPS 140CSfC

MAX The fastest thing flying. Fully capable. Completely rugged.

TuffServ^® 540

PRODUCT

DATASHEET

Features

Removable Storage Capacity Up To 16 TB
Small And Lightweight 105 cu. In, And Less Than 10 lbs
Optional Optical 10 GbE Interface
Expandability And Flexibility: Customizable I/O Options
Special Radiant Tolerant Version Suitable For High Altitude And Space

Size/Weight

2.9” H x 4.25” W  x 8.5” D

10 lbs

Speed

800 MB/sec

Storage

16 TB

Interfaces

2x GbE10/100 Fast Ethernet

Security

AES 256/FIPS 197FIPS 140CSfC

TuffServ^® 640v2

PRODUCT

DATASHEET

Features

Removable Storage Capacity Up To 300 TB
Quad 10 GbE Optical Interfaces
Suitable For Edge-Operating AI/ML Applications; Tested And Validated
Expandability And Flexibility: Customizable I/O Options
Can Record IRIG 106 Chapter 10 data format

Size/Weight

7.63” H x 4.88” W x 12.63″ D

30 lbs

Speed

3 GB/sec

Storage

300 TB

Interfaces

4x 10GbE, 1 GbE

Security

AES 256/FIPS 197FIPS 140CSfC

FLIGHT TEST Where every pulse, signal, and sensor detail matters.

miniRv2

PRODUCT

DATASHEET

Features

IRIG 106 CH 10 File Format
Outputs CH 10/11 Data As A CH 7 Serial PCM Stream
Totally Flexible & Modular I/O
Sustained Data Rates To 1,000 Mb/sec
Up To 2 TB Of Removable Storage

Size/Weight

4.125” H x 3.5” W x 6.82” D

4.6 lbs

Speed

1,000 Mb/sec

Storage

2 TB

Interfaces

1 GbE10/100 Fast EthernetRS 232/422″Slice-based” expansion

Fully expandable “Slice-based” system supports a multitude of interfaces

Security

AES 256/FIPS 197FIPS 140TurnstileCSfC

RACK MOUNT Where industry-leading design meets peak operational performance.

TRS-X

PRODUCT

DATASHEET

Features

Sustained Data Rate Of 100 Gb/sec
Scalable: Virtually Unlimited Storage/Capacity
QSFP Optical Interfaces
Multiple Expansion Sites For Additional I/O
Industry Standard Architecture And Commodity SSDS

Size/Weight

19” W x 3.5” H x 20” D (Chassis), 19” W x 1.75” H x 22” D (Removable Storage Tray)

40 lbs

Speed

Config A: up to 100Gb, Config B: 10-40Gb

Storage

187 TB+, Varies by Configuration

Interfaces

2x 100 GbE2x GbE (1 Shared with IPMI)

Security

AES 256/FIPS 197FIPS 140CSfC

DOWNLOAD STATION Efficient data download, encryption key handling, and data encryption/decryption.

SmartDock®

PRODUCT

DATASHEET

Features

miniRv2 or TuffCORD RMM rapid data download
Encryption key handling and data management
Fast 10 Gb/s network support
LCD panel for status
Easy-to-use Web GUI interface for status, download, and encryption key management

Size/Weight

4.5” H x 8.6” W 9.2” D

4.75lbs

Speed

10 Gb/s

Storage

Interfaces

10 GbE download interface

Security

AES 256/FIPS 197, FIPS-140, CSfC
